Lab9 Pro is the B2B division of Lab9, Belgium’s leading Apple Premium Partner. With over 30 years of experience, Lab9 Pro specializes in integrating and supporting Apple systems within businesses, educational institutions, and public organizations. Beyond Apple expertise, Lab9 Pro also designs, implements, and maintains complete IT infrastructures, including networks, servers, storage, and security solutions.
The challenge
It’s impossible to manage devices at organizations without the use of a good MDM (Mobile Device Management) system such as Jamf. As the leading provider of Apple device management solutions, Jamf empowers organizations to deploy, manage, and secure Apple devices at scale.
Even in smaller organizations Jamf is the right solution, as small and medium-sized enterprises (SMEs) often lack the resources to manage their MDM systems. Offering an MSP model solves a lot of problems for these customers.
For Apple device management, the typical customer has a few certificates issued by Apple, which require approval of the user agreement by the Apple business or school manager. Without getting too technical about Apple Device management, depending on the customer the certificates need to be renewed on different dates. If the user agreement is not approved, automated device enrollment will stop working.
Lab9 Pro found themselves needing to check all certificates and user agreements for MSP customers manually, which involved an unacceptably high error rate that often caused discontinuity of the MDM system.
The solution
Lab9 Pro were already using Zabbix to monitor customer environments and their own infrastructure, including storage, firewalls, switches, and more. Because Zabbix offers a wide variety of options that make it possible to monitor almost anything, it was only logical to explore whether Zabbix could also be used to monitor the MDM certificates.
The research phase
Step one was to check the availability of certificate information. Unfortunately, Apple Business Manager’s API did not help much, as it does not provide certificate details. Instead, the team at Lab9 Pro investigated the Jamf API.
Although it doesn’t directly return certificate information either, they found something even more useful – Jamf’s API provides customer instance notifications. These include alerts when certificates (VPP, PUSH, DEP, etc.) are about to expire (typically 10 days in advance) as well as when the Device Enrollment Program (user agreement) is not approved.
Zabbix implementation
Since Lab9 Pro manages multiple MSP tenants, they created a dedicated Zabbix template. This template includes both pre-filled and empty macros:
Pre-filled macros:
• {$JAMF.AUTH.INTERVAL}: Interval for retrieving the bearer token
• {$JAMF.NOTIF.INTERVAL}: Interval for retrieving Jamf notifications
• {$JAMF.PATH.AUTH}: API path for retrieving the bearer token
• {$JAMF.PATH.NOTIFICATIONS}: API path for retrieving Jamf notifications
Empty macros:
• {$JAMF.URL}: Jamf URL
• {$JAMF.API.USER}: Jamf user account for authentication
• {$JAMF.API.PASSWORD}: Jamf password (stored as a secret value)
The team configured an item to perform an API call to retrieve the bearer token. A preprocessing rule in JavaScript stores this token in a variable. Discovery rules proved very useful for executing API calls to retrieve Jamf notifications using the bearer token. This was achieved by configuring preprocessing steps and Low-Level Discovery (LLD) macros to pass the Jamf URL and bearer token. Trigger prototypes for each certificate were also added within the same discovery rule.
The results
Whenever a certificate is nearing expiration, a problem is automatically displayed on Lab9 Pro’s Zabbix dashboard, which is visible on TV screens placed throughout their office in order to make sure the entire team is aware of upcoming certificate renewals.
Since Lab9 Pro began monitoring MDM certificates through the Jamf API, they have experienced zero expired certificates, which in turn has allowed them to avoid situations where devices become unmanaged and require a full setup again.
Zabbix makes it possible for Lab9 Pro to keep their clients’ MDM systems operational, while allowing them to either proactively inform them when certificates need to be renewed or handle the renewal process on their behalf.
