The Ministry of Infrastructure and Water Management is the Dutch ministry responsible for transport, aviation, housing policy, public works, spatial planning, land management, and water resource management. Created in 2010 following the merger of the Ministry of Transport and Water Management and the Ministry of Housing, Spatial Planning, and Environment, the ministry works to create an efficient network of roads, railways, waterways, and airways, effective water management to protect against flooding, and improved air and water quality.
The challenge:
The ministry needed a monitoring solution that could handle not only infrastructure monitoring, but also IoT devices responsible for monitoring water levels, water quality, temperature, and other data. The infrastructure components that needed to be monitored included Red Hat Satellite and Capsule servers, Red Hat Virtual Data Centers, Red Hat Identity management, Ansible automation platforms, and a wide range of custom IoT devices.
The solution:
The Red Hat Satellite and Capsule monitoring consists of one satellite, 6 server, and 15 satellite capsules for different environments, with approximately 2000 Linux machines connected to the satellite capsules. The machines retrieve their packages from the capsules and the capsules act as proxies that fetch data from the satellite servers. The capsules also manage the content packages and subscriptions for the machines.
For Red Hat satellite and Capsule monitoring, Zabbix performs capsule discovery via Low Level Discovery, which uses Http requests, which in turn collect data via the REST API. Each capsule’s content sync status is monitored and if the content sync fails, new packages are not installed. Connectivity between capsules and the satellite is also monitored by performing port checks, because capsules need to be able to connect to the satellite in order for the content to be synced.
Zabbix also discovers and monitors satellite repositories, checking both when the last sync was performed and the current sync status. Software subscriptions are also discovered and monitored and alerts are sent, with the severity of the alerts raised at the point when a subscription has only 30 days remaining.
Red Hat Virtual Data Center licences and identity management also benefit from the added flexibility that Zabbix brings to the table. Virtual DC licences must be present on ESX hosts, so situations where an ESX host with an active license has no VMS on it (or has VMS migrated to it) must be avoided, because that would mean that a license is being essentially wasted. Whenever a Zabbix trigger detects a problem, Ansible automatically attaches or detaches a licence to or from the ESX host, depending on the type of problem detected.
When it comes to Red Hat identity management, Zabbix discovers and monitors processes on the identity management platform (including identity management service status) thanks to the ability to extend Zabbix agent with user parameters.
Meanwhile, Ansible Automation Platform monitoring consists of monitoring for controllers. The Ansible Automation Platform API is used to discover the controllers, and each controller is checked to see if any jobs are running, their last seen time, their capacity, and their status. Sometimes controllers are disabled for maintenance and then re-enabled, so alerts are sent out for controllers that have been disabled for a longer time.
Ansible Automation Platform monitoring also includes monitoring decommission machines, which are assigned to a group instead of being immediately deleted. Zabbix monitors the grace period for the decommission machines and alerts users if the grace period is over, generating a warning if an Ansible host is disabled for seven days and then escalating it if the machine has been disabled for more than 14 days.
Zabbix also discovers and monitors configuration management jobs, and if a job fails it will attempt to restart it. If the issue is still not resolved, it gets escalated to the appropriate individual. These Ansible checks are primarily done via Http agents, from Zabbix servers or proxies.
Finally, in addition to infrastructure monitoring, Zabbix also monitors the health of IoT devices responsible for water levels, water quality, temperature, and other data. These devices are running Raspberry Pi modules and Zabbix Agent 2 is used to monitor the device status. Zabbix Agent 2 with a local agent database is used in cases where the agent is unable to send the metrics on these devices. Should a network outage happen, Zabbix stores the backlog data in the local agent database.
The results:
Trusting their monitoring to Zabbix has greatly improved processes at the ministry, saving time and money by making it easy to notice and fix issues before affected departments themselves were aware of them. In addition, having the latest historical data at their fingertips has been invaluable to the ministry’s technical teams during troubleshooting or when dealing with performance issues, saving everyone involved a great deal of time.
In conclusion
Zabbix’s flexible nature and its ability to integrate with popular platforms as well as custom devices made it the perfect “one-stop shop” for the ministry’s needs, consolidating all of their monitoring in a single pane of glass and giving them complete visibility into every layer of their infrastructure – while also integrating smoothly with their existing systems.
